Description
The M6-25B is a black coated metal bolt that is used to assemble 17 of the 18 different connectors in the Flexpipe system. This bolt and the M6-N nut are the foundation of every Flexpipe structure.
We highly recommend that you keep a box or two of M6-25B at all times, since you will use a lot of them for all your structures.
The M6-25B bolt was designed to assemble Flexpipe HJ joints, and it was created to do only that. We don’t recommend that you use this part with the M6-N nut to connect anything other than the Flexpipe system.
Installation Steps:
See the installation steps tab to view how to assemble this bolt.
Technical Information:
This bolt is fixed to the M-6N using a 5mm T-HANDLE allen wrench.
(It is essential that the bolt is tightened between 12-14 N.m torque)
Antistatic Version (ESD):
Be sure to select the antistatic version M6-25BWZ for all the ESD connectors. This version is nickel-plated to provide the same ESD characteristics as the Nickel Plated joints.
Want to reuse parts of your old system?
The M6-25BÂ Flexpipe is compatible with many other pipe and connector systems. Check the technical information tab to know which systems are compatible and none-compatible with our parts.
