W-8PSB
8" Swivel Plate Caster with Brake
$0.00
Fast Shipping quote upon checkout
In stock
Various payment methods available
Ready for dispatch upon order confirmation
8″ Swivel Plate Caster with Brake
$0.00
- 1200 lb (500 kg) loading capacity
- 2.5 mph maximum speed
- Easy to push with polyurethane wheel thread
- Total brake lock for secure handling
Description
This Ergonomic 8” Swivel Plate-Mount Caster with Brake is ideal for heavy carts that require manual pushing. Its design reduces push/pull force, thanks to the optimized height and polyurethane (PU) wheel thread. The PU material handles debris, resists oil and grease, and withstands impacts.
The caster features a total brake lock, securing both the wheel and swivel rig for maximum stability. With maintenance-free double-sided sealed precision ball bearings, this caster ensures smooth performance.
Supporting loads up to 1200 lb (500 kg), it is built with a solid thread, a 5 mm thick steel fork, and a top plate compatible with standard mounting holes, like the W-6PSB model. It can also be used with Flexpipe’s Square Series framing, ideal for manual push carts at walking speed.
Fo
- 8x F-W516r secure installation, this caster requires the following hardware (not included):
- 4x WF-LARGE
- 4x M8-45B
- 4x M8-N
Additional information
| Diameter | |
|---|---|
| Loading capacity | |
| Type | |
| Installation | |
| ESD |
| Box Quantity | 6 |
|---|---|
| Height | 9.5 in (240.5 mm) |
| Width | 2 in (50 mm) |
| Weight (kg/lbs) | 12.6 lb (5.7 kg) |
| Box Dimensions | Cardboard box of 18 X 11 X 12 in (460 X 280 X 300 mm) |
| Common Usage | Manual hand push cart such as WIP carts, Kitting carts, Transport carts |
| Primary Material | Red Polyurethane (PU) for wheel thread |
| Secondary Material | 3/16'' (5 mm) thick steel for caster support |
| Temperature Resistance | -22°F to 158°F (-30°C to 70°C) |
| Frequency of Use | Medium |
| Electric Conductivity (ESD) | No |
| Loading Capacity | 1200 lb ( 500 kg) |
